Master Parts List Thread
« Thread Started on Sept 18, 2007, 8:51pm »

I try to keep this part number thread updated with all relevant parts number and descriptions as I find or need them. If you have a seven digit factory part number and/or description not listed you'd like to share, please post it and I'll add it to the list.

EXTERIOR PARTS

EXTERIOR, Grille:

74-78 Plastic grille 3734002, 3824453
74-78 Grille top edge retainers 6027479
"CAUTION Do Not Spill Brake Fluid On Plastic Grille" decal 3824626
74-78 Headlight door, R 3494216
74-78 Headlight door, L 3494217
74-78 Headlight door, bright 3734286
74-78 Headlight door retaining screw 9416208
74-78 Headlight door-to-grille-screw retaining nut 6013116
78 Plymouth Grille Emblem 4081524
71-73 Aluminum Grille 2956538
71-73 "DODGE" chrome grille nameplate 2956546
71-72 "FARGO" chrome grille nameplate 3490502
71-78 Grille parking light housing 3635966
71-72 Grille parking light lens w/concentric rings 2958512
71-78 Grille parking light lens & gasket, amber 3744293
71-78 Grille parking light lens & gasket, clear 3744300

EXTERIOR, Hood:

71-78 Front hood edge moulding 3734585
71-78 Front hood edge moulding retainer 6003499
71-78 Rear hood edge moulding 3837912
Weld stud repair screw 6024271
Letter "D", 1st 3734514
Letter "O" 3734515
Letter "D", 2nd 3734516
Letter "G" 3734517
Letter "E" 3734518
Letter "F" 3734511
Letter "A" 3734512
Letter "R" 3734513
Letter "G" 3734517
Letter "O" 3734568
Letter retaining nut 9420254
78 "PLYMOUTH" hood nameplate 4081416

EXTERIOR, Doors & Trim:

69-70 R outside door handle 2081338
69-70 L outside door handle 2081339
R outside door handle 64-71 (black knob) 2956452
64-71 door handle gasket 2504167
Mirror base (5x7), RH 2956968, 4083558, 3498610
Mirror base (5x7), LH 2956969, 3498611, 3731361
Mirror head (5x7), chrome 4083557, 4216042, 4216043
Mirror head (5x7), painted 3737186
Street Van emblems, metal 4083391, 4087165
Street Van decals 4038365A
74-78 "Voyager" side & rear door nameplate 4081378
71-77 "Dodge" rear door nameplate 2958772
71-72 "Fargo" rear door nameplate 3490499
D-shaped rubber front door bumpers 2255231
Door striker 3454485, 3494901
Cargo door hinge, upper right 2956671
Cargo door hinge, upper left 2956670
Cargo door hinge bushing 2956676

EXTERIOR, Body Trim:

71-77 front bumper 2959527
71-78 L Front fender edge molding, chrome 3734587
71-78 R Front fender edge molding, chrome 3734586
71-77 Side marker light assembly, amber 3489895
71-77 Side marker light assembly, red 3489894
71-77 Side marker light assembly, gasket 2958180
Primed gas cap 3496968
Chrome gas cap 4031476
Antenna 3879429
69-71 Wiper arm pivot & washer nozzle 2958501
Direct Connection front spoiler P4265309, P3690880
70-71 Pickup side marker lens, amber 2958059
70-71 Pickup side marker lens, red 2958062
70-71 Pickup side marker light housing, chrome 2958061
78 Plymouth A-pillar bottom chrome molding, L 4081347
78 Plymouth A-pillar bottom chrome molding, R 4081346

EXTERIOR, Tailights:

Tail light bezel, Chrome, L 2956817, S/A 3493197
Tail light bezel, Chrome, R 2956816, S/A 3493196
Tail light lens & gasket 3420913
Tail lamp 2958768

EXTERIOR, Glass & Trim:

71-'77 Lower windshield molding 2956768
71-'77 R windshield molding 3579074
71-'77 L windshield molding 3579075
71-'77 Upper windshield molding 3579078
Windshield molding clips 6002615
71-77 Cargo door vent window hinge 2503855, 2956772
71-73 Cargo door vent window latch (long style) 2956580
74-77 Cargo door vent window latch (short style) 3824232
Front door window glass travel stop 2956982

EXTERIOR, Body Sheetmetal:

Left rear body corner sheetmetal 3636659
Right rear body corner sheetmetal 2956373
R fender to headlight panel 2956810
L fender to headlight panel 2956811

EXTERIOR, Weatherstrip:

RF door weatherstrip 2956194
LF door weatherstrip 2956195
Front side cargo door weatherstrip 2956356
Rear side cargo door weatherstrip 2956357
Left rear cargo door weatherstrip 2956359
Right rear cargo door weatherstrip 2956358
Windshield gasket 3493882
Channel Run, Door division 2956205, 4082009
Channel run, top & rear piece 2956190
74 Engine Cover Seal/Gasket 3493330
75-77 Engine Cover Seal/Gasket 3739046

INTERIOR PARTS

INTERIOR, Electrical & Switches

71-77 Rear heater switch power wire 2958911
71-77 Rear heater power wire, cab side 3489470
71-77 Rear heater switch dash bezel 2911125
“RR HTR” SWITCH KNOB & STEM 2958828
Headlamp switch 2291880
Turn signal switch, '70-'77 4293101, 3489474
70-'72 Lighter knob, raised lettering 2958625
Decal, wash/wipe 3730564
Ignition switch courtesy light time-delay relay 2889565
Ignition switch courtesy light time-delay relay w/light 2958826

INTERIOR, Trim

71-74 Instrument cluster housing, metal 3738908
71-77 Horn pad, brown w/woodgrain & "DODGE" 3491109
71-77 Hord pad base 2771534
Instrument cluster outer trim ring w/chrome band 2958654
71-77 Cargo door upper garnish trim, L 3490842
71-73 Dash pad, tan 2958750
Sill scuff mat, L 3734042
Sill scuff mat, R 3734043
Side stepwell scuff pad 3734569
Upper plastic interior panel, RR, 127" w.b. Sportsman 3490762
Upper plastic interior panel, LR, 127" w.b. Sportsman 3497063
Upper plastic interior panel, RF, 127" w.b. Sportsman 3734585
Upper plastic interior panel, LF, 127" w.b. Sportsman 3490783
Sunvisor center support 4038379
71-73 Heating/coolingcontrol bezel, non-A/C 2911105
Brake or clutch pad 2955312
71-72 Cargo door handle 2956723
73-77 Cargo door handle 3729159
4-speed shifter boot 2950201, 3467764, 2660390
Clutch pedal lever 2955468
L rubber floor mat, Black 3490388
L rubber floor mat, Blue 3490389
L rubber floor mat, Green 3490390
R rubber floor mat, Black 34903994
R rubber floor mat, Blue 3490395
R rubber floor mat, Green 3490396
Chrome headliner molding 3729311
Chrome headliner molding end cap 3490896
71-'77 Throttle pedal 2961579
Armrest base 2589583, 3734764
Sunvisor, black 3490795
Radio delete bezel, black 3489306

UNDERHOOD

ENGINE Compartment:

Underhood equipment sticker 4032333
Power steering pressure hose 3489412
Windshield Washer Fluid Reservoir 3489411
78-'81 Radiator Overflow Reservoir 3821465
Wiper motor resistor 3870089
P/S pump pulley 3821546
Radiator overflow reservior 2958953
Heater valve 2216552
Speedo cable firewall grommet 2956554
Battery tray 3489444
Chrome brake master cylinder cover (DirConn) 4120225
Brake bellcrank pivot rod bushing 2467770
Voltage regulator 4091050, 4111990, 4379100

CHASSIS & Underside:

Fuel tank srap support stud 3492091
Gas tank strap J-bolt 3838440, 6033708
23 gal fuel tank sending unit 4075096
36 gal fuel tank sending unit 4028935
35 tooth speedo pinion gear 3879267
75-'77 Front parking brake cable 4030193
Shifter adapter plate, four-speed floor shift 3893789
Sending unit 3837440
A-833 Inspection Cover Gasket 2464037
Front shock absorber 4086417
70-83 Parking brake cable 3491013
Rear spring framerail bumpstop 3496691
Speedometer cable- cruise control servo-to-transmission 2958836

« Last Edit: Jul 12, 2010, 3:42pm by Casey »

Link to Post - Back to Top IP:

Logged

Street Van- The Adult Toy from Dodge

[image]

1tuffsportsman
member is offline

[avatar]

A Dogs Life!

Joined: Apr 2010
Gender: Male

Posts: 521
Location: DESERT PLAINS

Re: Master Parts List Thread
« Reply #1 on Apr 25, 2010, 11:00pm »

There ya go. That's a great resource, thanks for posting.

Link to Post - Back to Top IP:

Logged

'76 Dodge B200 Sportsman Royal SE D-code/440

Parts hauler for above;
'76 Dodge W200 Crew Cab short bed D-code

vanman2
member is offline

Joined: May 2010
Gender: Male

Posts: 210

Re: Master Parts List Thread
« Reply #2 on Jun 14, 2010, 6:42pm »

WOW Casey ~~~ thanks for posting your list ~~~ great help & resource

Link to Post - Back to Top IP:

Logged

74PB300
member is offline

Joined: Aug 2009
Gender: Male

Posts: 64
Location: Ridgecrest Ca.

Re: Master Parts List Thread
« Reply #3 on Nov 9, 2010, 3:14pm »

Thanks Casey!

Link to Post - Back to Top IP:

Logged

Rob
'74 Plymouth Voyager PB300
'64 Chrysler 300
'67 Plymouth Valiant
[image]

alikazam
member is offline

[avatar]

Magical Van Man

Joined: Jul 2008
Gender: Male

Posts: 34
Location: Beaverton, OR

Re: Master Parts List Thread
« Reply #4 on Aug 21, 2011, 10:47pm »

Great resource, thanks for posting

Link to Post - Back to Top IP:

Logged

1972 Dodge Van, B100, Tradesman, Short Wheelbase
12.13 @ 107.06 mph (lifting before end) on Nitrous

135sohc
member is offline

Joined: Aug 2011
Gender: Male

Posts: 48

Re: Master Parts List Thread
« Reply #5 on Aug 22, 2011, 4:18pm »

Quote:

D-shaped rubber front door bumpers 2255231

Are these the 3 pieces per side that go on the B pillar? And if so is it known if chrysler still has them ?

Link to Post - Back to Top IP:

Logged

Casey
4-speeds Have More Fun
member is offline

[avatar]

Joined: May 2007
Gender: Male

Posts: 1,999
Location: Menomonee Falls, WI

Re: Master Parts List Thread
« Reply #6 on Aug 22, 2011, 4:59pm »

Aug 22, 2011, 4:18pm, 135sohc wrote:

Quote:

D-shaped rubber front door bumpers 2255231

Are these the 3 pieces per side that go on the B pillar? And if so is it known if chrysler still has them ?

Yes, that's correct.

I don't know if they are still available new, and/or if there's a newer supercede part number for them, but you can go to www.arizonaparts.com and do a search.

I believe some very similar pieces are reproduced, but they are just a tad longer than those used on vans, so you either need to shorten the arrow-shaped barb on the bottom, or trim the entire piece.

Link to Post - Back to Top IP:

Logged

Street Van- The Adult Toy from Dodge

[image]

135sohc
member is offline

Joined: Aug 2011
Gender: Male

Posts: 48

Re: Master Parts List Thread
« Reply #7 on Aug 22, 2011, 6:44pm »

Awesome, I spent an hour looking in the microfiche trying to find those and get a p/n as mine are very ratty and 2 are missing.

metro does make one in two different lengths but its not tall enough to stick out far enough and actually do anything to prevent rattles and movement of the door shell.

Link to Post - Back to Top IP:

Logged

Casey
4-speeds Have More Fun
member is offline

[avatar]

Joined: May 2007
Gender: Male

Posts: 1,999
Location: Menomonee Falls, WI

Re: Master Parts List Thread
« Reply #8 on Aug 22, 2011, 9:18pm »

I think late '60s B-body pieces have the same bulb shape in cross section, but are a bit longer.

Link to Post - Back to Top IP:

Logged

Street Van- The Adult Toy from Dodge

[image]

finallyavannin
member is offline

Joined: Jun 2010
Gender: Male

Posts: 574
Location: Westchester Calif.

Re: Master Parts List Thread
« Reply #9 on Aug 23, 2011, 9:33pm »

Man I am glad I got mine when I did. Looks like the supply of these are drying up.
There was a lot of dealers that had them when I looked on Partsvoice back when I got them.

They also may be falling out of the system due to age and no demand. Hope that's the case.
Mine are a 1/4" too long but the rest of the dimensions are the same. No biggie to cut.

Richard

Link to Post - Back to Top IP:

Logged

'75 B200

Casey
4-speeds Have More Fun
member is offline

[avatar]

Joined: May 2007
Gender: Male

Posts: 1,999
Location: Menomonee Falls, WI

Re: Master Parts List Thread
« Reply #10 on Aug 30, 2011, 10:05am »

I found a pic of the door bumper I had:

[image]

Link to Post - Back to Top IP:

Logged

Street Van- The Adult Toy from Dodge

[image]

b300
member is offline

4 Wheel Power Disc Brakes

Joined: Sept 2010
Gender: Male

Posts: 348
Location: Western US

Re: Master Parts List Thread
« Reply #11 on Aug 30, 2011, 11:12am »

I reused 80's bumpers on mine, works fine. (The trick is removal without damaging them.)

Link to Post - Back to Top IP:

Logged

B-300

iamzardoz
member is offline

[avatar]

Joined: Nov 2011
Gender: Male

Posts: 365

Re: Master Parts List Thread
« Reply #12 on Nov 20, 2011, 9:41am »

Very helpful list (esp. for us newbies), thanks for posting.

Link to Post - Back to Top IP:

Logged

IamZardoz

tnichols71
member is offline

Joined: Dec 2011
Gender: Male

Posts: 21
Location: Springfield, MO

Re: Master Parts List Thread
« Reply #13 on Dec 24, 2011, 1:10am »

great list Casey!!! as usual! do you happen to know the part number for the big radio/ a/c /heater bezel? mine says 1701075 tan! but i don't think that's the right number. it is burnt in some spots.

« Last Edit: Dec 24, 2011, 1:28am by tnichols71 »

Link to Post - Back to Top IP:

Logged

Click Here To Make This Board Ad-Free
